Multi Layers Thermal Automatic Lamination Machine , Max Φ800mm Heat Laminator Machine In White And Blue

Name: Multi Layers Thermal Automatic Lamination Machine Max Φ800mm Heat Laminator Machine In White And Blue
Brand: Laiyi
Price: 70 USD

China Multi Layers Thermal Automatic Lamination Machine , Max Φ800mm Heat Laminator Machine In White And Blue wholesale

Brand Name : Laiyi

Model Number : ACP

Place of Origin : China

MOQ : 1 set

Price : $70,000-400,000

Payment Terms : L/C , T/T

Supply Ability : Max 20sets per month

Delivery Time : 90-150 days

Packaging Details : Sea worthy packaging

Certification : CE

type : film laminating machine

condition : new

automatic gra : automatic

driven type : mechanical

voltage : 380V

lifetime : more than 10 year

Contact Now

Jiangsu Laiyi has been highly recognized and praised in domestic extrusion laminating industry since 2007 and has increasing market share.As more and more cooperation relationships with foreign enterprises, Jiangsu Laiyi has established a good reputation in the international market.

Jiangsu Laiyi is working on becoming one of the first class packing machinery manufacturers in the world by our professional quality and superior service Professional extrusion laminating line established by more than 10 years of working can provide long time services for large enterprises both at home and abroad with professional researches.

一,Color Printing Packaging Extrusion Laminating Machine

Color printing packaging paper is widely used to
1)food packaging materials and liquid packaing materials;
2)Non-woven fabrics compound with color printing films/ woven fabrics compound with alumium foils/ aluminum-plastic compound etc.
Can be Co-extrusion and Mono extrusion line
We also make customized machine.
This is a double station tumble initiative automatic unwinding and rewinding line.

二,Technical parameters of Color printing packaging extrusion laminating machine.

Item	LY-ACP2-1200	LY-ACP2-1400	LY-ACP2-1700	LY-ACP2-2200	LY-ACP2-2500
Effective laminating width:	max1100mm	max1300mm	max1600mm	max2100mm	max2400mm
Machine speed:	200-250m/min
Screw diameter:	φ80mm,φ90mm,φ100mm,φ110mm
Max unwinder&rewinder diameter:	φ800mm
Sandwich diameter:	φ600mm
Max output:	180kg/h,200kg/h,300kg/h or 400kg/h
Coated resins:	LLDPE/LDPE/PP/EVA/EAA
Laminating thickness range:	8-45μm
Base material:	Aluminium foil/ Non-woven fabric /Metalized film/ BOPP/ BOPET/ BOPA,etc(10-200gsm)
Sandwich material:	CPE / CPP/ PET/Aluminium foils
Dimension:	Co-extrusion:19.55(9.5-14)4.7m
	Mono extrusion: 11.65(9.5-14)3.8m

三,Main Features

1) Double Shaft-less paper roll stands suitable for 3-6 inch paper core,automatic lift ,easier operation .

2) Auto splicer device realize paper in 150-300 m/min speed exchange without decrease machine line speed

3) Ultrasonic type EPC system,makes frequent replacement materials operation more simple

4) Hydraulic lamination structure design , can make coating thinner and firm .

5) Trimming device make the finished coated paper rolls even

6)Special cutting knife and rewinder design makes high speed rewinding shafts exchange possible

Double station unwinder:

It applies to multiple materials and has a wide range of us.
It can automatically change rolls without stopping machine or reduce speed.
It has one-button and no-button type operation, is simple and conveniet.
It occupies small area, can save the production spaces.

Double station rewinder:

It can automatically change rolls without stopping machine or reducing speed.
It applies to multiple materials and has a wide range of uses, has different way to control tension of different material.
It uses suspension type press roller to rewind, the tension of multiple materials can be controlled to guarantee the smooth and beauty of the production surface.

Multi Layers Thermal Automatic Lamination Machine , Max Φ800mm Heat Laminator Machine In White And Blue

" Professional qualifications to create brand" is Laiyi's business objective!

"Create excellece by quality, prvide service with honesty" is

Laiyi's business prupose!
